5083 5754 anodized Aluminium Plate 3003 alu coil custom steel plate
brushed aluminium sheet
As China aluminum coil supplier, we are looking forward to forming
successful business relationships with new clients around the world
in the near future.Our eternal pursuits are the attitude of ,regard
the market, regard the custom, regard the science, and the theory
of ,quality the basic, trust the first and management the advanced,
for , we are now looking forward to even greater cooperation with
overseas customers based on mutual benefits. If you are interested
in any of our products, please feel free to contact us for more
details.
Aluminum
Sheet | aluminum Plate is available in various alloys offering a range
of weldability, corrosion resistance and machinability.
Aluminum sheet is any aluminum sheet metal thicker than foil but
thinner than 6mm; it comes in many forms including diamond plate,
expanded, perforated and painted aluminum sheet. Aluminum plate is any aluminum sheet metal that is thicker than 6mm
Available aluminum sheet grade
1000 series:1050,1060,1070,1080,1100,1145,1200,1235, etc.
2000 series:2014,2017,2018,2024,2025,2219, 2219,2618a etc.
3000 series:3003,3004,3102,3104,3105,3005, etc.
4000 series:4032,4043, 4017, etc
5000 series: 5005,5052,5454,5754,5083,5086,5182,5082, etc.
6000 series:6061,6063,6262,6101, etc
7000 series:7072,7075,7003 etc
8000 series: 8011, etc.
Temper of aluminum sheet: O, H, W, F, T
H:H12, H14, H16, H18, H19, H22, H24, H26, H32, H34, H111, H112,
H114, H116
T: T0-T651
Size of aluminum sheet
Thickness:0.2-6.0mm
Width:100-2400mm
Length:200-11000mm
Mother coil: CC or DC
Weight: About 2mt per pallet for general size
MOQ: 5ton per size
Protection: paper inter layer, white film, blue film, black-white
film, micro bound film, according to your requirement.
Surface: clean and smooth, no bright speck, corrosion, oil,
slotted, etc.
Standard product: GBT3880, JIS4000, EN485, ASTM-B209
Delivery time: about 30days after receiving the deposit
Payment: T/T, L/C at sight
Trading terms: FOB, CIF, CFR
Application of aluminum sheet
Aluminum sheet is used in construction material and building material. Including:
roof panel, ceiling, in-wall, partition wall, shutters, window
blind, gate, balcony, wall, road marking, street signs, road
protecting plate, highway protecting plate, bridge carrier wall,
scaffold, ship plate, etc.
Aluminum sheet is used in electric machine components. Including: protective
plate, protective box, capacitor box, tank of power capacitor,
electrolytic condenser, variable of battery, volume shaft,
loudspeaker framework, switch plate, semi-conductor radiator,
magnetic disk, motor frame, fan blade, electric cooker, cooling
fin, heat sink, etc.
Alloy 1100 is a low strength aluminum alloy with excellent
corrosion resistance. This grade is best used for welding, brazing
and soldering but has poor machinability. 1100 aluminium alloy plate has great finishing capabilities so it is a great choice for
decorative purposes.
A commercially pure aluminum, Aluminium alloy plate 1100 contains
no more than one percent of other chemical elements. It is your
standard aluminum alloy containing a minimum of 99.0% aluminum. It
is formable, weldable, and its ability to take a form is excellent.
Typical markets include chemical equipment, reflectors, heat
exchangers, architectural applications, and many more
Alloy available: 1050 1060 1100 3003, 3105, 5052, 5005, 5754 5083
5182, 6061 6063 6082, 7075, 8011…
Temper: HO, H111,H12, H14, H24,H 32, H112, T4, T6, T5,T651
Surface:Mill | Emboss | Diamond | 2bar | 3bars | Bright
Thickness: 0.2mm to 300mm
Width: 30mm to 2300mm
Length:1000mm to 10000mm
RUIYI Aluminum is a professional manufacturer and supplier of 1100 aluminium alloy plate based in China. We also offer aluminum coil, PVDF aluminium coil,
aluminum sheet, coated aluminum coil, diamond aluminum tread
plate,and more. Whenever you have a need for any of our products,
please feel free to contact us.
| Chemical Analysis of aluminum alloy Plate |
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | - | 0.05 | 0.03 | Remains |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | - | - | - | - | - | Remains |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | - | - | - | - | Remains |
| 1100 | 0.95 | 0.95 | 0.05-0.2 | 0.05 | - | - | 0.1 | - | - | Remains |
| 1200 | 1 | 1 | 0.05 | 0.05 | - | - | - | 0.1 | 0.05 | Remains |
| 3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | - | - | - | 0.1 | - | Remains |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5-1.1 | 0.1 | - | 0.25 | - | Remains |
| 5042 | 0.2 | 0.35 | 0.15 | 0.2--.5 | 3.0-4.0 | 0.1 | - | 0.25 | 0.1 | Remains |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | - | 0.1 | - | Remains |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4-1.0 | 4.0-4.9 | 0.05-0.25 | - | 0.25 | - | Remains |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | - | 0.2 | - | Remains |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | - | 0.25 | - | Remains |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45 | 0.1 | - | 0.1 | - | Remains |
| 6082 | 0.7-1.3 | 0.5 | 0.1 | 0.4-1.0 | 0.6-1.2 | 0.25 | - | 0.2 | - | Remains |
| 7050 | 0.12 | 0.15 | 2.0-2.6 | 0.1 | 1.9-2.6 | 0.04 | - | 5.7-6.7 | 0.06 | Remains |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | - | 5.1-6.1 | 0.2 | Remains |
