Commercial 5052 marine grade aluminium alloy sheet plate for boat
Aluminium alloy plate 5052 in H32 temper has very good corrosion
resistance to seawater and marine and industrial atmosphere. It
also has very good weldability and good cold formability. It is a
medium to high strength alloy with a strength slightly higher than
5251 and a medium to high fatigue strength.
Alloy aluminium plate 5052-H32 has a range of useful properties:
Decorative Finish | Hard Wearing | Non-Slip | Corrosion Resistant |
Low Maintenance | Anti-Static | Light-weight
Amongst the applications for Aluminium Alloy 5052 plate are:
Treadplate | Boilermaking | Containers | Nameplates| Road Signs |
Architectural Paneling | Welded Tubes | Chemical Industry |
Irrigation | Desalination units | Pressure Vessels | Rivets
Features of 5052 aluminum alloy plate include higher fatigue
strength than most aluminum alloys, excellent resistance to salt
water atmosphere, excellent weldability and workability, and
excellent finishing characteristics
Aluminium alloy 5052 contains nominally 2.5% magnesium & 0.25%
chromium. It has good workability, medium static strength, high
fatigue strength, good weldability, and very good corrosion
resistance, especially in marine atmospheres. It also has the low
density and excellent thermal conductivity common to all aluminium
alloys. It is commonly used in sheet, plate and tube form.
What We can supply
Alloy: 1050 1060 1100 3003, 3105, 5052, 5005, 5754 5083 5182, 6061
6063 6082, 7075, 8011…
Temper: HO, H111,H12, H14, H24,H 32, H112, T4, T6, T5,T651
Surface finish: Mill / Emboss / Diamond / 2 bar / 3 bars / Bright /
Mirror
Thickness: 0.2mm to 300mm
Width: 30mm to 2300mm
Length:1000mm to 10000mm.
| Chemical Analysis of aluminum alloy Plate |
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Ti | Al |
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | - | - | 0.05 | 0.03 | Remains |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | - | - | - | - | - | Remains |
| 1070 | 0.2 | 0.25 | 0.04 | 0.03 | 0.03 | - | - | - | - | Remains |
| 1100 | 0.95 | 0.95 | 0.05-0.2 | 0.05 | - | - | 0.1 | - | - | Remains |
| 1200 | 1 | 1 | 0.05 | 0.05 | - | - | - | 0.1 | 0.05 | Remains |
| 3003 | 0.6 | 0.7 | 0.05-0.2 | 1.0-1.5 | - | - | - | 0.1 | - | Remains |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.5-1.1 | 0.1 | - | 0.25 | - | Remains |
| 5042 | 0.2 | 0.35 | 0.15 | 0.2--.5 | 3.0-4.0 | 0.1 | - | 0.25 | 0.1 | Remains |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2-2.8 | 0.15-0.35 | - | 0.1 | - | Remains |
| 5083 | 0.4 | 0.4 | 0.1 | 0.4-1.0 | 4.0-4.9 | 0.05-0.25 | - | 0.25 | - | Remains |
| 5754 | 0.4 | 0.4 | 0.1 | 0.5 | 2.6-3.6 | 0.3 | - | 0.2 | - | Remains |
| 6061 | 0.4-0.8 | 0.7 | 0.15-0.4 | 0.15 | 0.8-1.2 | 0.04-0.35 | - | 0.25 | - | Remains |
| 6063 | 0.2-0.6 | 0.35 | 0.1 | 0.1 | 0.45 | 0.1 | - | 0.1 | - | Remains |
| 6082 | 0.7-1.3 | 0.5 | 0.1 | 0.4-1.0 | 0.6-1.2 | 0.25 | - | 0.2 | - | Remains |
| 7050 | 0.12 | 0.15 | 2.0-2.6 | 0.1 | 1.9-2.6 | 0.04 | - | 5.7-6.7 | 0.06 | Remains |
| 7075 | 0.4 | 0.5 | 1.2-2.0 | 0.3 | 2.1-2.9 | 0.18-0.28 | - | 5.1-6.1 | 0.2 | Remains |
